VPN/PPTP Static Routes Loose Gateway When Client Reconnects

---

Recently i configured a site to site vpn connectivity (Head office to Branch office) at some place. Everything was working fine , both end clients could access each other with direct access as proper routes were setup, But strange issue was happening that if the branch office mikrotik goes offline or Re connects the pptp dialer,    static route at head office mikrotik becomes un-reachable

(manual route was added at H.O mikrotik to access branch offices via dynamic pptp interface).

---

As showed in the image below … (head office router)

---

It was happening because the route is looking at a dynamic interface. When the dynamic interface goes away (branch office mikrotik pptp disconnect-reconnect) the Route does not know which interface to point to. . To sort this issue, I added ROUTE in ppp/secret section @ Head Office mikrotik.

As showed in the image below ….

.

---

The above subnet 192.168.88.0/24 is branch office clients subnet. now whenever the branch will re connect the pptp, a dynamic route will add each time on H.O mikrotik, so it will know that from which route it should access B.O clients.

As showed in the image below.

.

---

TIP:

You can do it manually too by assigning static ip, and in route use that ip in gateway, But I prefer to use dynamic route , because the route will be created dynamically each time when user connected to the router and disappear when user disconnect. And so the route will work transparently even if changes are made in other sections.

Read More

Hotspot self registration PHP form with captcha and SMS/Email function

---

TASK:

It is required that user can connect to open WiFi network (probably running Mikrotik hotspot system) and upon browsing he will see the login page with REGISTER option as well. User can self register his account on radius billing system by using PHP FORM[for example can be used in FREE WiFi environment, exhibition, conference rooms, resorts etc].

It is also useful if you want to provide trial/free internet access but want to log all the required info , like mobile numbers, contacts, and there usage with control.

Upon submissions, PHP form will execute Linux bash script with the supplied data, and then it should perform various checks , example.

• User must enter no less or more  then 11 numeric digits in MOBILE field.
• User must enter no less or more  then 13 numeric digits in CNIC field.
• User must enter correct CAPTCHA image code in order to submit the form. It is required in order to prevent BRUTE force attack using automated scripting.
• If the user is registering for the first time, his account will be registered with specific service (the service must be added by admin, and its name is configurable in reg.sh script file. The system will send SMS (and print screen , you can configure it as per the requirements) to user mobile number supplied in the form with the login , validity and other information.
• The user should be allowed 3 hours for the current day (or as per the profile configured in reg.sh)
• If the user consumed 3 hours within the same date and try to register again, he will be denied with the information message that he have already registered with the same mobile and account status will be provided like still ACTIVE or EXPIRED and that he should try again next day (date).
• If the user still have balance and account is active, he should be informed accordingly.
• If the user have expired (dueto DATE OR UPTIME hours limit) and next date arrived, he can register again, and INFO SMS message (and print screen , you can configure it as per the requirements) will be sent to use informing that his previously registered account got renewed with the login , validity and other information.

---

Components Used:

1- Ubuntu
2- Apache Web Server
3- Radius Manager as Billing system in working condition
4- GSM Modem used to send SMS to containing the information
5- KANNEL as SMS gateway
6- Captcha code software for prevention of BRUTE force attack, Make sure to install it in /var/www/reg/securimage, test it to make sure its showing images properly.

---

SCRIPTS:

Following PHP page and scripts should be copied to /var/www/reg folder [for ubuntu]

1. user.php [User Input Registration Form]
2. reg-display.php [Displays the User Input Result and execute the Script which executes the action]
3. reg.sh [main script that executes the action based on supplied information by reg-display.sh]

---

1- user.php [User Input Registration Form]

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65

<!DOCTYPE html> <html> <head> <link href="http://ajax.googleapis.com/ajax/libs/jqueryui/1.8/themes/base/jquery-ui.css" rel="stylesheet" type="text/css"/> <script src="http://ajax.googleapis.com/ajax/libs/jquery/1.5/jquery.min.js"></script> <script src="http://ajax.googleapis.com/ajax/libs/jqueryui/1.8/jquery-ui.min.js"></script> <script> $(document).ready(function() { $("#start_datepicker").datepicker({ dateFormat: 'yy-mm-dd' }); $("#end_datepicker").datepicker({ dateFormat: 'yy-mm-dd' }).bind("change",function(){ var minValue = $(this).val(); minValue = $.datepicker.parseDate("yy-mm-dd", minValue); minValue.setDate(minValue.getDate()+1); $("#to").datepicker( "option", "minDate", minValue ); }) }); </script> </head> <body style="font-size:62.5%;"> <form action="reg-display.php" method="post"> <h1><font color="blue">Register yourself to get one hour internet access for current day.<br></font> <br><br>   <pre> MOBILE NUMBER    : <input pattern=".{11,11}" onkeypress='return event.charCode >= 48 && event.charCode <= 57' name="mobile" cnic="11 characters minimum" maxlength="11">  [11 Numeric Digits Only Without dash/space]   CNIC NO        : <input pattern=".{13,13}" onkeypress='return event.charCode >= 48 && event.charCode <= 57' name="cnic" cnic="13 characters minimum"maxlength="13">  [13 Numeric Digits Only Without dash/space]   FIRST NAME    : <input type="text" name="firstname">   LAST NAME    : <input type="text" name="lastname">   <br></h1> </pre> <input type="submit" value="Submit:">   <img id="captcha" src="/securimage/securimage_show.php" alt="CAPTCHA Image" /> <input type="text" name="captcha_code" size="10" maxlength="6" /> <a href="#" onclick="document.getElementById('captcha.).src = '/securimage/securimage_show.php?. + Math.random(); return false">[ Different Image ]</a>   </form> </body> <br> <br>   <?php $ip = ""; if (!empty($_SERVER["HTTP_CLIENT_IP"])) { //check for ip from share internet $ip = $_SERVER["HTTP_CLIENT_IP"]; } elseif (!empty($_SERVER["HTTP_X_FORWARDED_FOR"])) { // Check for the Proxy User $ip = $_SERVER["HTTP_X_FORWARDED_FOR"]; } else { $ip = $_SERVER["REMOTE_ADDR"]; } echo "<pre><h2>YOUR IP Address is        : $ip</h2></pre>"; ?>   <h3><font color="red">This System is powered by Syed_Jahanzaib aacable@hotmail.com </html>

---

2- reg-display.sh [Displays the User Input Result and execute the Script which executes the action]

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

<?php   include_once $_SERVER['DOCUMENT_ROOT'] . '/securimage/securimage.php'; $securimage = new Securimage(); if ($securimage->check($_POST['captcha_code']) == false) { echo "The CAPTCHA security code entered was incorrect. Make Sure You are HUMAN - zaib!<br /><br />"; echo "Please go <a href='javascript:history.go(-1)'>back</a> and try again."; exit; }   $MOBILE = $_POST['mobile']; $CNIC = $_POST['cnic']; $FIRSTNAME = $_POST['firstname']; $LASTNAME = $_POST['lastname'];   $ip = "";   if (!empty($_SERVER["HTTP_CLIENT_IP"])) { //check for ip from share internet $ip = $_SERVER["HTTP_CLIENT_IP"]; } elseif (!empty($_SERVER["HTTP_X_FORWARDED_FOR"])) { // Check for the Proxy User $ip = $_SERVER["HTTP_X_FORWARDED_FOR"]; } else { $ip = $_SERVER["REMOTE_ADDR"]; }   echo "<h2><u>You have entered the following information:</u></h2>"; echo "<pre>Mobile        : $MOBILE</pre>"; echo "<pre>CNIC No        : $CNIC</pre>"; echo "<pre>Firstname    : $FIRSTNAME</pre>"; echo "<pre>Lastname    : $LASTNAME</pre>"; echo "<pre>IP Address is    : $ip</pre>";     echo "<h2><u>BILLING RESPONSE</u></h2>"; $var = shell_exec("TERM=xterm /var/www/reg/reg.sh $MOBILE $CNIC $ip $FIRSTNAME $LASTNAME"); echo "<pre>$var</pre>";   ?>

---

3- reg.sh [main script that executes the action based on supplied information by reg-display.sh]

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264

#!/bin/sh # CREATE NEW USER VIA PHP/HTML INPUT FORMS AND ADD IN MYSQL DB, MADE FOR RADIUS MANAGER # LOTS OF VAROIUS CHECKS added # CREATED : 17-FEB-2016 # LAST MODIFIED = # set -x   # ======================================================================================================================== # Service name (exact) you want to provide to temporary hotspot users - CHANGE IT FOR SURE - valid for RADIUS MANAGER only SRVNAME="hotspot1mb" # ========================================================================================================================     SQLUSER="root" SQLPASS="MYSQL_PASSWORD" COMPANY="JAHANZAIB-PVT-LTD" NEXTEXPIRYADD=$(date +"%Y-%m-%d" -d "+1 days") CURDATE=$(date +"%Y-%m-%d") CURDATEWOD=`date +%Y%m%d` TIME=`date | awk {'print $4'}`   # KANNEL RELATED INFORMATION KID="kannel" KPASS="KANNEL_PASSWORD" KHOST="127.0.0.1"   ################################# ###### DONOT EDIT BELOW  ######## #################################   # Create temporary holder if not already there, for the user data and empty it as well touch /tmp/$1.txt > /tmp/$1.txt echo $1 $2 $3 $4 $5  >> /tmp/$1.txt   MOBILE=`cat /tmp/$1.txt |awk '{print $1}'` CNIC=`cat /tmp/$1.txt |awk '{print $2}'` IP=`cat /tmp/$1.txt |awk '{print $3}'` FIRSTNAME=`cat /tmp/$1.txt |awk '{print $4}'` LASTNAME=`cat /tmp/$1.txt |awk '{print $5}'`   # Look for user service ID - Example 1mbps service SRVID=`mysql -u$SQLUSER -p$SQLPASS -e "use radius; SELECT srvid FROM radius.rm_services WHERE rm_services.srvname = '$SRVNAME';" |awk 'FNR == 2 {print $1}'`   # Look for user Registration date REGDATE=`mysql -u$SQLUSER -p$SQLPASS -e "use radius; SELECT createdon FROM radius.rm_users WHERE rm_users.username = '$MOBILE';" |awk 'FNR == 2 {print $1}'`   # Look for registration date without digits for comparision REGDATEWOD=`mysql -u$SQLUSER -p$SQLPASS -e "use radius; SELECT createdon FROM radius.rm_users WHERE rm_users.username = '$MOBILE';" |awk 'FNR == 2 {print $1}' | sed 's/-//g'`   #LOOK FOR VALID USER IN RADIUS USRVALID=`mysql -uroot -p$SQLPASS -e "use radius; SELECT username FROM radius.rm_users WHERE rm_users.username = '$MOBILE';" |awk 'FNR == 2 {print $1}'`   # Look for EXPIRATION CUREXPIRY=`mysql -uroot -p$SQLPASS --skip-column-names  -e "use radius; SELECT expiration FROM radius.rm_users WHERE rm_users.username = '$MOBILE';"`   # Look for UPTIME Limit - usually in hour unit format e.g : 1 , also it will be shown for user friendly format later UPTIMELIMIT=`mysql -uroot -p$SQLPASS --skip-column-names  -e "use radius; SELECT timeunitonline FROM rm_services WHERE srvid = '$SRVID';"`   # Get UPTIME limit in seconds so that it can etner correctly in user propfile, seconds format also required for MYSQL TABLE for correct entry FUPTIME=`echo "$UPTIMELIMIT*60*60" | bc`   # Welcome Message for NEW or returning User if [ "$MOBILE" = "$USRVALID" ]; then echo "Welcome back Mr. $FIRSTNAME $LASTNAME!" else echo "Welcome NEW User" fi   # Check for registered Date, if no previous registeration date found, then treat user as NEW if [ -z "$REGDATEWOD" ]; then echo "No registration Date found previosly, treating it as a new user. proceed to new create new user"   # Add user in MYSQL TABLE now mysql -u$SQLUSER -p$SQLPASS -e "use radius; INSERT INTO rm_users ( username, password, downlimit, uplimit, comblimit, firstname, lastname, company, phone, mobile, email, address, city, zip, country, state, comment, mac, expiration, enableuser, usemacauth, uptimelimit, srvid, staticipcm, staticipcpe, ipmodecm, ipmodecpe, createdon, acctype, createdby, taxid, maccm, credits, owner, groupid, custattr, poolidcm, poolidcpe, contractid, contractvalid, gpslong, gpslat, alertemail, alertsms, lang) VALUES ( '$MOBILE', MD5('$MOBILE'), '0', '0', '0', '$FIRSTNAME', '$LASTNAME', '', '', '', '', '', '', '', '', '', '', '', '$NEXTEXPIRYADD', '1', '', '$FUPTIME', '$SRVID', '', '', '', '0', NOW(), '0', 'admin', '', '', '0.00', 'admin', '1', '', '', '', '', '', '', '', 1, 1, 'English' );"   # Add user access in RADCHECK Table and SYSLOG as well mysql -u$SQLUSER -p$SQLPASS -e "use radius; INSERT INTO radcheck (UserName, Attribute, op, Value) VALUES ('$MOBILE', 'Cleartext-Password', ':=', '$MOBILE');" mysql -u$SQLUSER -p$SQLPASS -e "use radius; INSERT INTO radcheck (UserName, Attribute, op, Value) VALUES ('$MOBILE', 'Simultaneous-Use', ':=', '1');" mysql -u$SQLUSER -p$SQLPASS -e "use radius; INSERT INTO rm_syslog (datetime, ip, name, eventid, data1) VALUES (NOW(), '$IP', 'ROBOT', '0', '$MOBILE');" #mysql -uroot -p$SQLPASS -e "use radius; INSERT INTO tempuser (mobile, firstname, lastname, cnic, rendate) VALUES ('zaib888mobile', 'testfirst', 'testlast', '234567890', '$CURDATE $TIME');"   # Look for EXPIRATION for NEW User (account created above) CUREXPIRY=`mysql -uroot -p$SQLPASS --skip-column-names  -e "use radius; SELECT expiration FROM radius.rm_users WHERE rm_users.username = '$MOBILE';"`   # OUTPUT RESULT FOR USER on SCREEN / OR BETTER TO SEND IT TO USER VIA SMS echo "Dear $FIRSTNAME $LASTNAME,   Your NEW account have been successfuly registered on $COMPANY System. You can use following login information to connect. Your IP  = $IP User ID  = $MOBILE Password = $MOBILE Validity = $CUREXPIRY Uptime   = $UPTIMELIMIT Hours   Regard's $COMPANY" > /tmp/$MOBILE.sms   cat /tmp/$MOBILE.sms   echo "Sending SMS to the registered Mobile number"   # Sending NEW ACCOUNT CREATION INFO  SMS to user mobile numbers curl "http://$KHOST:13013/cgi-bin/sendsms?username=$KID&password=$KPASS&to=$MOBILE" -G --data-urlencode text@/tmp/$MOBILE.sms   else   ####################################### # Check for ACCOUNT status for ACTIVE OR EXPIRED STATUS="" ESTATUS="" LTATUS=""   QSTATUS=`mysql -uroot -p$SQLPASS --skip-column-names  -e "use radius; SELECT SQL_CALC_FOUND_ROWS username, firstname, lastname, address, city, zip, country, state, phone, mobile, email, company, taxid, srvid, downlimit, uplimit, comblimit, expiration, uptimelimit, credits, comment, enableuser, staticipcpe, staticipcm, ipmodecpe, ipmodecm, srvname, limitdl, limitul, limitcomb, limitexpiration, limituptime, createdon, verifycode, verified, selfreg, acctype, maccm, LEFT(lastlogoff, 10) , IF (limitdl = 1, downlimit - COALESCE((SELECT SUM(acctoutputoctets) FROM radacct WHERE radacct.username = tmp.username) - (SELECT COALESCE(SUM(dlbytes), 0) FROM rm_radacct WHERE rm_radacct.username = tmp.username), 0), 0),   IF (limitul = 1, uplimit - COALESCE((SELECT SUM(acctinputoctets) FROM radacct WHERE radacct.username = tmp.username) - (SELECT COALESCE(SUM(ulbytes), 0) FROM rm_radacct WHERE rm_radacct.username = tmp.username), 0), 0),   IF (limitcomb =1, comblimit - COALESCE((SELECT SUM(acctinputoctets + acctoutputoctets) FROM radacct WHERE radacct.username = tmp.username) - (SELECT COALESCE(SUM(ulbytes + dlbytes), 0) FROM rm_radacct WHERE rm_radacct.username = tmp.username), 0), 0),   IF (limituptime = 1, uptimelimit - COALESCE((SELECT SUM(acctsessiontime) FROM radacct WHERE radacct.username = tmp.username) - (SELECT COALESCE(SUM(acctsessiontime), 0) FROM rm_radacct WHERE rm_radacct.username = tmp.username), 0), 0)   FROM ( SELECT username, firstname, lastname, address, city, zip, country, state, phone, mobile, email, company, taxid, rm_users.srvid, rm_users.downlimit, rm_users.uplimit, rm_users.comblimit, rm_users.expiration, rm_users.uptimelimit, credits, comment, enableuser, staticipcpe, staticipcm, ipmodecpe, ipmodecm, srvname, limitdl, limitul, limitcomb, limitexpiration, limituptime, createdon, verifycode, verified, selfreg, acctype, maccm, mac, groupid, contractid, contractvalid, rm_users.owner, srvtype, lastlogoff FROM rm_users JOIN rm_services USING (srvid)   ORDER BY username ASC ) AS tmp WHERE 1 AND username LIKE '$MOBILE%' AND (tmp.acctype = '0'  OR tmp.acctype = '6' ) AND tmp.enableuser = 1 AND (IF (limitdl = 1, downlimit - (SELECT COALESCE(SUM(acctoutputoctets), 0) FROM radacct WHERE radacct.username = tmp.username) - (SELECT COALESCE(SUM(dlbytes), 0) FROM rm_radacct WHERE rm_radacct.username = tmp.username) , 1) <= 0 OR IF (limitul = 1, uplimit - (SELECT COALESCE(SUM(acctinputoctets), 0) FROM radacct WHERE radacct.username = tmp.username) - (SELECT COALESCE(SUM(ulbytes), 0) FROM rm_radacct WHERE rm_radacct.username = tmp.username) , 1) <= 0 OR IF (limitcomb = 1, comblimit - (SELECT COALESCE(SUM(acctinputoctets + acctoutputoctets), 0) FROM radacct WHERE radacct.username = tmp.username) + (SELECT COALESCE(SUM(ulbytes + dlbytes), 0) FROM rm_radacct WHERE rm_radacct.username = tmp.username) , 1) <= 0 OR IF (limituptime = 1, uptimelimit - (SELECT COALESCE(SUM(acctsessiontime), 0) FROM radacct WHERE radacct.username = tmp.username) + (SELECT COALESCE(SUM(acctsessiontime), 0) FROM rm_radacct WHERE rm_radacct.username = tmp.username) , 1) <= 0 OR IF (limitexpiration=1, UNIX_TIMESTAMP(expiration) - UNIX_TIMESTAMP(NOW()), 1) <= 0)   LIMIT 0, 50;"`     # Store STATUS for ACTIVE OR EXPIRED in VARIABLE if [ -z "$QSTATUS" ]; then FSTATUS="ACTIVE" else FSTATUS="EXPIRED" fi   # IF user registered today, then DONOT RE_REGISTER the USER and EXIT THE SCRIPT / zaib if [ "$REGDATEWOD" -eq "$CURDATEWOD" ]; then echo "Dear Mr. $FIRSTNAME $LASTNAME   INFO: This mobile number is already allowed to use intenret for today!   Account Details: USER ID = $MOBILE STATUS = $FSTATUS Expiration    = $CUREXPIRY Uptime Limit = $UPTIMELIMIT - Hours   For same day, you cannot register new account or Renew old account on same mobile number   $COMPANY " > /tmp/$MOBILE.sms   cat /tmp/$MOBILE.sms   echo "Sending SMS to the registered Mobile number"   # Sending DENIAL (already registered and ACTIVE)  SMS to user mobile numbers curl "http://$KHOST:13013/cgi-bin/sendsms?username=$KID&password=$KPASS&to=$MOBILE" -G --data-urlencode text@/tmp/$MOBILE.sms   exit 0 fi   # IF Account is ACTIVE AND VALID FOR TODAY, then INFORM USER AND EXIT THE SCRIPT   if [ "$FSTATUS" = "ACTIVE" ]; then echo "Account Already ACTIVE Validity = $CURDATE Uptime   = $UPTIMELIMIT Hours"   exit 0 fi   # IF USER is ALREADY IN DB, AND STATUS IS EXPIRED, AND VALID FOR RENEWAL (24 HOURS PASSWED) THEN RENEW THE USER : ) / zaib mysql -uroot -p$SQLPASS --skip-column-names  -e "use radius; UPDATE rm_users SET downlimit = '0', uplimit = '0', comblimit = '0', expiration = '$NEXTEXPIRYADD', uptimelimit = '$UPTIMELIMIT', warningsent = 0 WHERE username = '$MOBILE';" # Add Renewal Info in SYSLOG mysql -u$SQLUSER -p$SQLPASS -e "use radius; INSERT INTO rm_syslog (datetime, ip, name, eventid, data1) VALUES (NOW(), '$IP', 'ROBOT', '0', '$MOBILE');"   # OUTPUT RESULT FOR USER on SCREEN / OR BETTER TO SEND IT TO USER VIA SMS echo "Dear $FIRSTNAME $LASTNAME,   INFO: Your account have been renewed successfully. You can use following login information.   User ID  = $MOBILE Password = $MOBILE Validity = $CURDATE Uptime   = $UPTIMELIMIT Hour   Regard's $COMPANY"  > /tmp/$MOBILE.sms   # Output DATA on screen for user cat /tmp/$MOBILE.sms   echo "Sending SMS to the registered Mobile number" # Sending Renewal SMS to user mobile numbers curl "http://$KHOST:13013/cgi-bin/sendsms?username=$KID&password=$KPASS&to=$MOBILE" -G --data-urlencode text@/tmp/$MOBILE.sms   fi   ### THE END, SCRIPT ENDS HERE ### ### MADE BY SYED JAHANZAIB ### ### AACALBE AT HOTMAIL DOT COM ### ### https://aacable.wordpress.com ###

---

SCRIPTS OUTPUT :

1- User Registration Page

UPON SUBMISSION YOU MAY GET BELOW RESULTS (AS PER THE INPUT PROVIDED BY THE USER)

---

2- Successful registration for the NEW user

and on SMS

---

3- Deny registration of same user for the same DATE

and on SMS

---

4- Allow renewal for the OLD users  if there account status is EXPIRED and registration date is not same.

and on sms

DONE !

---
